The Sports Lighter (SP1) is a high-performance LED floodlight designed to deliver powerful, flexible illumination for sports venues, stadiums, and large outdoor environments. Available in white, RGB, and RGBW models, it allows you to choose high-output white lighting for peak visibility or dynamic color-changing effects to elevate atmosphere, branding, and live event experiences.
Engineered for demanding outdoor use, the SP1 features a rugged die-cast aluminum housing with advanced thermal management to ensure reliable performance in all conditions. Its IP65 wet-location rating protects against dust, water, and harsh weather, making it a dependable solution for year-round operation in challenging environments.
Designed with installers in mind, the SP1 offers multiple mounting options and a streamlined installation process that helps reduce labor time and project costs. Adjustable tilt, compact design, and remote driver capability provide added flexibility for precise aiming and simplified maintenance.
The SP1 supports standard 0–10V dimming for reliable everyday control, with optional DALI, D4i, and DMX-RDM systems for advanced lighting scenes and sports applications. It is also compatible with fast-switching sports lighting controls, enabling instant response for game-ready lighting, seamless event transitions, and dynamic on-demand control.
Applications: Sports Lighting.
White, RGB and RGBW Models
Choose high-performance white illumination or dynamic color-changing options for enhanced atmosphere, and event versatility.
Wet Location Rated (IP65)
The fixture withstands extreme outdoor weather conditions and it is protected against dust, water, and contaminants.
Easy to Install and Operate
Versatile mounting options and a quick installation design helps contractors, installers and end users save time and money.
Fixture Performance
| Size | Lumen Output | Watts | Efficacy | Lens | Part Number |
|---|---|---|---|---|---|
| MD | 90,000 | 600 | 150 | N33 | SP10S-A2-90K-MD-50-80-N33-LV… |
| MD | 119,000 | 800 | 149 | N33 | SP10S-A2-119K-MD-50-80-N33-LV… |
| LG | 180,000 | 1,200 | 149 | N33 | SP10S-A2-180K-LG-50-80-N33-LV… |
Technical Specs
CONSTRUCTION
ELECTRICAL
OPERATION
OPTICS
MOUNTING
CONTROLS
WARRANTY
LISTINGS & CERTIFICATIONS
CONSTRUCTION
- Housing: Aluminum die-cast.
- Housing Color: Gray. Other colors available upon request.
- Heat Sink: Cast aluminum.
ELECTRICAL
- Power Input: 120-277V or 200-480V (50/60Hz).
- Power Factor: Greater than 0.9.
- Total Harmonic Distortion: Less than 20%.
- Surge Protection: 20kV/20kA, standard.
OPERATION
- Environment: Wet location for exterior applications. IP65 rated.
- Ambient Range Operation: -40°C up to 45°C (-40°F up to 113°F).
OPTICS
-
- CCT: 4000K, 4500K, 5000K, or 5700K.
- CRI: 70+ standard.
- Lens: NEMA symmetric and asymmetric distribution patterns available (1×1, 2×2, 3×3, 4×4, 4×5, and 5×5).
- Glare Shields: Standard.
MOUNTING
- Mounting Options: Trunnion, Slip Fitter, and Knuckle brackets.
CONTROLS
- Dimming: 0-10V standard (dimming range 100% to 10%). DALI2/D4i and DMX-RDM drivers available as an option.
- Fast-Switching Sports Lighting Controls: Synapse controls available as an accessory (must order DALI option). Additional accessories, services and subscriptions available, contact factory.
WARRANTY
- 5 Year Performance Warranty: Fixture is guaranteed for 5 years, including LEDs and driver. “Defective” is considered if ten percent (10%) or more of the LEDs, per product, are non‐operating LEDs, or color temperature has shifted more than 500° Kelvin within the warranty period. See terms and conditions at https://linmoreled.com/warranty
LISTINGS & CERTIFICATIONS
- cUL.
- UL 1598.
- RoHS compliant.
- IP65 rated.
- IK08 rated.
- 20kV/20kA surge protection as per ANSI/IEEE C62.41.
- DesignLights™ Consortium Premium.
