The new Ace LED Area Light (AA1) is a revolution in area lighting fixtures thanks to its modern aesthetics, ease of installation and versatility for contractors, installers, and end users.
Integrated switches allow to select three color temperatures: 3000K/4000K/5000K, and four output wattages per model. MD: 75/100/120/150W and LG: 175/200/240/300W.
Optics are interchangeable and can be swapped on the field by opening two latches (no tools needed), while keeping its IP65 rating. Another pair of latches provides tool-less access to LED driver compartment for simple replacement if needed.
Its EZ-Connect receptacle provides the option to add motion sensors, photocells and UltraLink Bluetooth controls to the fixture any time after installation with a Twist and Lock System.
Applications: Automotive Lighting, Commercial Lighting, Outdoor Lighting, Parking Garage Lighting, Sports Lighting.
Selectable Wattage and CCT
Integrated switches in the fixture allow to select four output wattage options and three color temperatures: 3000K, 4000K, or 5000K.
Easy Swap Lenses
Open two latches to change the optic lens in seconds without tools while keeping the IP65 rating. Available optics: T2, T3, T4, and T5.
EZ-Connect Receptacle
The simplest and fastest way to add sensors and UltraLink wireless controls at any time in the field. Twist Lock System, no tools or wiring needed.
Performance
| Size | Selectable Watts | Selectable CCT | Lumen Output | Efficacy | Part Number |
|---|---|---|---|---|---|
| MD | 75 | 3000K | 10,500 | 140 | AA10S-A2-ADJ-MD-ADJ-80-T3-LV-BRN-BB-EZ10-CW-SRG-10V |
| MD | 75 | 4000K | 11,250 | 150 | AA10S-A2-ADJ-MD-ADJ-80-T3-LV-BRN-BB-EZ10-CW-SRG-10V |
| MD | 75 | 5000K | 10,875 | 145 | AA10S-A2-ADJ-MD-ADJ-80-T3-LV-BRN-BB-EZ10-CW-SRG-10V |
| MD | 100 | 3000K | 14,000 | 140 | AA10S-A2-ADJ-MD-ADJ-80-T3-LV-BRN-BB-EZ10-CW-SRG-10V |
| MD | 100 | 4000K | 15,000 | 150 | AA10S-A2-ADJ-MD-ADJ-80-T3-LV-BRN-BB-EZ10-CW-SRG-10V |
| MD | 100 | 5000K | 14,500 | 145 | AA10S-A2-ADJ-MD-ADJ-80-T3-LV-BRN-BB-EZ10-CW-SRG-10V |
| MD | 120 | 3000K | 16,800 | 140 | AA10S-A2-ADJ-MD-ADJ-80-T3-LV-BRN-BB-EZ10-CW-SRG-10V |
| MD | 120 | 4000K | 18,000 | 150 | AA10S-A2-ADJ-MD-ADJ-80-T3-LV-BRN-BB-EZ10-CW-SRG-10V |
| MD | 120 | 5000K | 17,400 | 145 | AA10S-A2-ADJ-MD-ADJ-80-T3-LV-BRN-BB-EZ10-CW-SRG-10V |
| MD | 150 | 3000K | 21,000 | 140 | AA10S-A2-ADJ-MD-ADJ-80-T3-LV-BRN-BB-EZ10-CW-SRG-10V |
| MD | 150 | 4000K | 22,500 | 150 | AA10S-A2-ADJ-MD-ADJ-80-T3-LV-BRN-BB-EZ10-CW-SRG-10V |
| MD | 150 | 5000K | 21,750 | 145 | AA10S-A2-ADJ-MD-ADJ-80-T3-LV-BRN-BB-EZ10-CW-SRG-10V |
| LG | 175 | 3000K | 24,500 | 140 | AA10S-A2-ADJ-LG-ADJ-80-T3-LV-BRN-BB-EZ10-CW-SRG-10V |
| LG | 175 | 4000K | 26,250 | 150 | AA10S-A2-ADJ-LG-ADJ-80-T3-LV-BRN-BB-EZ10-CW-SRG-10V |
| LG | 175 | 5000K | 25,375 | 145 | AA10S-A2-ADJ-LG-ADJ-80-T3-LV-BRN-BB-EZ10-CW-SRG-10V |
| LG | 200 | 3000K | 28,000 | 140 | AA10S-A2-ADJ-LG-ADJ-80-T3-LV-BRN-BB-EZ10-CW-SRG-10V |
| LG | 200 | 4000K | 30,000 | 150 | AA10S-A2-ADJ-LG-ADJ-80-T3-LV-BRN-BB-EZ10-CW-SRG-10V |
| LG | 200 | 5000K | 29,000 | 145 | AA10S-A2-ADJ-LG-ADJ-80-T3-LV-BRN-BB-EZ10-CW-SRG-10V |
| LG | 240 | 3000K | 33,600 | 140 | AA10S-A2-ADJ-LG-ADJ-80-T3-LV-BRN-BB-EZ10-CW-SRG-10V |
| LG | 240 | 4000K | 36,000 | 150 | AA10S-A2-ADJ-LG-ADJ-80-T3-LV-BRN-BB-EZ10-CW-SRG-10V |
| LG | 240 | 5000K | 34,800 | 145 | AA10S-A2-ADJ-LG-ADJ-80-T3-LV-BRN-BB-EZ10-CW-SRG-10V |
| LG | 300 | 3000K | 42,000 | 140 | AA10S-A2-ADJ-LG-ADJ-80-T3-LV-BRN-BB-EZ10-CW-SRG-10V |
| LG | 300 | 4000K | 45,000 | 150 | AA10S-A2-ADJ-LG-ADJ-80-T3-LV-BRN-BB-EZ10-CW-SRG-10V |
| LG | 300 | 5000K | 43,500 | 145 | AA10S-A2-ADJ-LG-ADJ-80-T3-LV-BRN-BB-EZ10-CW-SRG-10V |
Technical Specs
- Housing: Aluminum die-cast, compact low profile design.
- Housing Color: Bronze (RAL 8019).
- Wireway Cover: Aluminum die-cast.
- Heat Sink: Cast aluminum.
- Latches: Tool-less access to driver and lens compartments.
- EZ-ConnectTM Receptacle: The simplest and fastest way to add sensors and wireless controls at any time on the field. Twist Lock System, no tools or wiring needed.
- Power Input: 120-277V or 277-480V (50/60Hz) typical, depending on model.
- Power Factor: Greater than 0.9.
- Total Harmonic Distortion: Less than 20%.
- Surge Protection: 10kV standard.
- Environment: Wet location for exterior applications. IP65 rated.
- Ambient Range Operation: -40°C up to 50°C
(-22°F up to 122°F).
- CCT: Selectable via switch 3000K, 4000K, 5000K.
- CRI: 80+ standard.
- Lens: UV stable clear polycarbonate. Replaceable on the field by opening two clasps, no tools needed.
- Mounting: The fixture comes with the bracket base attached to it. Slip Fitter, Straight Arm, and Trunnion (Yoke) brackets are field installed (see Accessories).
- Dimming: 0-10V standard. Dimming range 100% to Off.
- Photocell Sensor: On/Off based on ambient light. EZ-Connect Twist Lock system for field installation.
- Occupancy Sensors: PIR and Microwave occupancy sensors, On/Off/Dim. EZ-Connect Twist Lock System for field installation.
- Networked Lighting Controls: UltraLink Wireless Controls with Bluetooth® NLC Mesh technology. EZ-Connect Twist Lock System for field installation.
- 5 Year Warranty: The fixture is guaranteed for 5 years free of defects in materials and workmanship, including LEDs and driver. “Defective” is considered if ten percent (10%) or more of the LEDs, per product, are non‐operating LEDs, or color temperature has shifted more than 500° Kelvin within the warranty period. See terms and conditions at https://linmoreled.com/warranty
- cUL, UL 1598.
- RoHS compliant.
- IP65 and IK08 rated.
- DesignLights™ Consortium Premium.
