The Large Area fixture (LA1) delivers powerful, uniform illumination for stadiums, sports fields, facades, and other expansive outdoor applications where performance and visual impact matter. Available in both high-performance white and dynamic RGB models, it provides the flexibility to create crisp functional lighting or vibrant color-changing effects for events, branding, and architectural enhancement.
Engineered for demanding environments, the LA1 features a rugged die-cast aluminum housing and integrated heat sink that maximize thermal performance to keep LEDs cooler and operating efficiently for years to come. Its corrosion-resistant construction, IP65/IP66 wet-location rating, and 3G vibration certification ensure dependable operation in harsh weather and challenging outdoor conditions.
Precision optical distributions and glare shields deliver uniform coverage with reduced spill light and improved visual comfort. Standard 0–10V dimming and optional fast-switching controls enable dynamic lighting scenes, instant on/off performance, and advanced automation.
Applications: Automotive Lighting, Hangar Lighting, Industrial Lighting, Outdoor Lighting, Parking Garage Lighting, Sports Lighting.
White and RGB Models
Choose high-performance white illumination or dynamic color-changing options for enhanced atmosphere, and event versatility.
Superior Heat Dissipation
Die-cast aluminum housing and heat sink improve thermal transfer, keeping LEDs cool to increase performance and life.
Wet Location Rated (IP65/IP66)
The fixture withstands extreme outdoor weather conditions and it is protected against dust, water, and contaminants. M Models: IP65; MS Models: IP66.
Fixture Performance
| Size | Lumen Output | Watts | Efficacy | Lens | Part Number | |
|---|---|---|---|---|---|---|
| 1MS | 46,500 | 300 | 155 | N33 | LA10S-A2-46K-1MS-50-70-N33-HV-GRY-TM-SRG20-10V | |
| 2MS | 93,000 | 600 | 155 | N33 | LA10S-A2-93K-2MS-50-70-N33-HV-GRY-TM-SRG20-10V | |
| 3MS | 139,500 | 900 | 155 | N33 | LA10S-A2-139K-3MS-50-70-N33-HV-GRY-TM-SRG20-10V | |
| 4MS | 186,000 | 1,200 | 155 | N33 | LA10S-A2-186K-4MS-50-70-N33-HV-GRY-TM-SRG20-10V | |
| 2M | 150,000 | 1,000 | 150 | N33 | LA10S-A2-150K-2M-50-70-N33-HV-GRY-TM-SRG20-10V | |
| 2M | 168,000 | 1,200 | 140 | N33 | LA10S-A2-168K-2M-50-70-N33-HV-GRY-TM-SRG20-10V | |
| 3M | 225,000 | 1,500 | 150 | N33 | LA10S-A2-225K-3M-50-70-N33-HV-GRY-TM-SRG20-10V | |
| 3M | 252,000 | 1,800 | 140 | N33 | LA10S-A2-252K-3M-50-70-N33-HV-GRY-TM-SRG20-10V |
Technical Specs
CONSTRUCTION
ELECTRICAL
OPERATION
OPTICS
MOUNTING
CONTROLS
WARRANTY
LISTINGS & CERTIFICATIONS
CONSTRUCTION
- Housing: Aluminum die-cast.
- Housing Color: Gray. Other colors available upon request.
- Heat Sink: Cast aluminum.
- Corrosion Resistance: Scribe creepage rating of 8 per ASTM D1654 after 500-hour salt fog exposure (ASTM B117-2019). Test Conditions: Temperature: 23.7°C; Humidity: 56% RH; Saline concentration: 5% NaCl; PH value: 7.0; Salt buckets temperature: 35°C; Pressure buckets temperature: 47°C; Spray volume: 1.5 ml/ 80cm2/h.
ELECTRICAL
- Power Input: 120-277V or 200-480V (50/60Hz).
- Power Factor: Greater than 0.9.
- Total Harmonic Distortion: Less than 20%.
- Surge Protection: 20kV/10kA, standard.
OPERATION
- Environment: Wet location for exterior applications. MS models are IP66 rated, M models are IP65 rated.
- Ambient Range Operation: -40°C up to 45°C (-40°F up to 113°F).
OPTICS
-
- CCT: 3000K, 4000K, 4500K, 5000K, or 5700K.
- CRI: 70+ standard.
- Lens: NEMA symmetric and asymmetric distribution patterns available (NEMA 1×1, 3×3, 4×4, 5×5, 4×5), depending on the model.
- Glare Shields: Included. Field installed.
MOUNTING
- Mounting Options: Integrated Trunnion bracket (standard).
CONTROLS
- Dimming: 0-10V standard (dimming range 100% to 10%).
- Fast-Switching Sports Lighting Controls: Synapse controls available as an accessory (must order DALI option). Additional accessories, services and subscriptions available, contact factory.
WARRANTY
- 5 Year Performance Warranty: Fixture is guaranteed for 5 years, including LEDs and driver. “Defective” is considered if ten percent (10%) or more of the LEDs, per product, are non‐operating LEDs, or color temperature has shifted more than 500° Kelvin within the warranty period. See terms and conditions at https://linmoreled.com/warranty
LISTINGS & CERTIFICATIONS
- cUL.
- UL 1598.
- RoHS compliant.
- IP66 rated (MS models). IP65 rated (M models).
- IK08 rated.
- 3G vibration rated as per ANSI C136.31-2023.
- Compliant with ANSI C82.77:2002 for THD requirements.
- 20kV/10kA surge protection as per ANSI/IEEE C62.41.
