The new Ace LED Canopy (AC2) is made to last with its rugged aluminum die-cast housing and shatter resistant lens. A silicon sealed gasket ensures dust, water, and contaminants do not enter the fixture.
Easy to install and maintain, this canopy fixture features integrated switches to select three output wattage options, 20W/30W/40W, and three color temperatures: 3000K/4000K/5000K.
Its integrated photocell makes this fixture perfect for energy-saving projects in all canopy and parking garage applications.
Applications: Commercial Lighting, Outdoor Lighting, Parking Garage Lighting.
Selectable Wattage and CCT
Integrated switches in the fixture allow to select three output wattage options and three color temperatures: 3000K, 4000K, or 5000K.
Wet Location Rated (IP65)
Includes a silicone gasket to ensure dust, water, and contaminants do not enter the fixture.
Integrated Photocell
Standard, installed inside the fixture, On/Off based on ambient light. It can be enabled or disabled with a switch.
Performance
| Size | Selectable Watts | Selectable CCT | Lumen Output | Efficacy | Part Number |
|---|---|---|---|---|---|
| MD | 20 | 3000K | 2,500 | 125 | AC20S-A2-ADJ-MD-ADJ-80-CL-LV-FXT-S-10V |
| MD | 20 | 4000K | 2,700 | 135 | AC20S-A2-ADJ-MD-ADJ-80-CL-LV-FXT-S-10V |
| MD | 20 | 5000K | 2,600 | 130 | AC20S-A2-ADJ-MD-ADJ-80-CL-LV-FXT-S-10V |
| MD | 30 | 3000K | 3,750 | 125 | AC20S-A2-ADJ-MD-ADJ-80-CL-LV-FXT-S-10V |
| MD | 30 | 4000K | 4,050 | 135 | AC20S-A2-ADJ-MD-ADJ-80-CL-LV-FXT-S-10V |
| MD | 30 | 5000K | 3,900 | 130 | AC20S-A2-ADJ-MD-ADJ-80-CL-LV-FXT-S-10V |
| MD | 40 | 3000K | 5,000 | 125 | AC20S-A2-ADJ-MD-ADJ-80-CL-LV-FXT-S-10V |
| MD | 40 | 4000K | 5,400 | 135 | AC20S-A2-ADJ-MD-ADJ-80-CL-LV-FXT-S-10V |
| MD | 40 | 5000K | 5,200 | 130 | AC20S-A2-ADJ-MD-ADJ-80-CL-LV-FXT-S-10V |
Technical Specs
- Housing: Aluminum die-cast.
- Housing Color: Bronze (RAL 8019).
- Heat Sink: Cast aluminum.
- Power Input: 120-277V (50/60Hz) standard.
- Power Factor: Greater than 0.9.
- Total Harmonic Distortion: Less than 20%.
- Flicker: Less than 2%.
- Emergency Battery Backup: EMB has 15 watts output, producing ~2,200 lumens for a minimum of 90 minutes. Sold as an accessory (field installed).
- Environment: Wet location for exterior applications. IP65 rated.
- Ambient Range Operation: -30°C up to 45°C (-22°F up to 1113°F).
- CCT: Selectable via switch 3000K, 4000K, 5000K.
- CRI: 80+ standard.
- Lens: Clear ribbed, 160° beam angle. Shutter resistant.
- Surface Mounting: Standard.
- Pendant Mounting: Stem 3/4” conduit installation (3/4” tube not included).
- Dimming: 0-10V standard. Dimming range 100% to Off.
- Photocell Sensor: Standard, On/Off based on ambient light. Disabled by default. It can be enabled or disabled with a switch.
- Occupancy Sensors: PIR and Microwave occupancy sensors, On/Off/Dim. EZ-ConnectTM Twist Lock System for field installation. Requires installation of elbow mount, sold separately.
(See Accessories). - Networked Lighting Controls: UltraLink Wireless Controls with Bluetooth® NLC Mesh technology. EZ-ConnectTM Twist Lock System for field installation. Requires installation of elbow mount, sold separately. (See Accessories).
- 5 Year Warranty: The fixture is guaranteed for 5 years free of defects in materials and workmanship, including LEDs and driver. “Defective” is considered if ten percent (10%) or more of the LEDs, per product, are non‐operating LEDs, or color temperature has shifted more than 500° Kelvin within the warranty period. See terms and conditions at https://linmoreled.com/warranty
- cUL, UL 1598.
- RoHS compliant.
- IP65 and IK10 rated.
- DesignLights™ Consortium Premium.
