The new Ace LED Wrap (AS2-R) combines exceptional performance with sleek, modern aesthetics. Its slim profile blends into any space, enhancing the environment with a clean and contemporary design.
Its high-quality frosted diffuser provides consistent, low-glare lighting, enhancing visibility and comfort in various applications.
This 4ft wrap fixture offers adjustable wattage options of 29W, 33W, and 39W. Users can easily select the color temperature (CCT) using a simple switch, choosing between 3500K, 4000K, or 5000K to adapt to different lighting needs.
Additionally, the EZ-Connect™ receptacle features a snap-in system that allows for easy integration of compatible motion sensors and UltraLink Bluetooth controls at any time.
Applications: Automotive Lighting, Commercial Lighting, Industrial Lighting, Office Lighting, Parking Garage Lighting, Warehouse Lighting.
Selectable Wattage
Each fixture has a switch with three output power options, allowing to select the desired lumen output and energy consumption.
CCT Adjustable
Simply use the switch directly on the fixture to select the desired color temperature for your space: 3500K, 4000K, or 5000K.
EZ-Connect™ Receptacle
The simplest and fastest way to add sensors and UltraLink wireless controls at any time in the field. Snap-in system, no tools or wiring needed.
Performance
| Size | Lumen Output | Efficacy | Watts | Part Number |
|---|---|---|---|---|
| 4ft | 3,625/4,125/4,875 | 125 | 29/33/39W | AS20R-A2-ADJ-04-ADJ-80-FR-LV-FXT-EZ40-10V |
Technical Specs
- Housing: Galvanized Steel. Low profile design.
- Housing Color: White.
- EZ-Connect™ Receptacle: The simplest and fastest way to add sensors and wireless controls at any time on the field. Snap-in system, no tools or wiring needed.
- Power Input: 120-277V (50/60Hz).
- Power Factor: Greater than 0.9.
- Total Harmonic Distortion: Less than 20%.
- Emergency Battery Backup: 8 Watts output. Fixtures with EMB will produce ~1,000lm for a minimum of 90 minutes. Field installed. Available as an accessory, sold separately.
- Environment: For interior applications, dust-resistant, listed for damp locations.
- Ambient Range Operation: -20°C up to 35°C
(-4°F up to 95°F).
- CCT: 3500K, 4000K, 5000K (selectable via switches).
- CRI: 80+ standard.
- Lens: Frosted prismatic PC diffuser. 110° beam angle.
- Surface Mount: Surface mount kit available as an accessory.
- Suspension Mount: Suspended mount kit available as an accessory.
- Dimming: 0-10V standard. Dim to Off. Dimming range 100% to 5%.
- Occupancy Sensors: PIR sensor, On/Off/Dim. EZ-Connect™ Snap-in system for field installation.
- Networked Lighting Controls: UltraLink Wireless Controls with Bluetooth® NLC Mesh technology. EZ Connect™ Snap-in system for field installation.
- 5 Year Warranty: The fixture is guaranteed for 5 years free of defects in materials and workmanship, including LEDs and driver. “Defective” is considered if ten percent (10%) or more of the LEDs, per product, are non‐operating LEDs, or color temperature has shifted more than 500° Kelvin within the warranty period. See terms and conditions at https://linmoreled.com/warranty
- UL listed.
- RoHS compliant.
- UL listed for damp locations.
- DesignLights™ Consortium Premium.
