ULPLUS-SMG

UltraLink+ Sound Masking Generator

The ULPLUS-SMG is a Bluetooth NLC Wireless Sound Masking Generator that delivers a subtle, airflow-like ambient sound through a connected speaker, creating private, comfortable workspaces.

Sound masking enhances speech privacy by making conversations less intelligible at a distance, reduces distractions in offices, hospitals, and call centers, and ensures a consistent, comfortable acoustic environment.

It connects via Bluetooth and can be accessed with the UltraLink+ web portal or mobile app for setup and configuration.

SPEC SHEET
ULPLUS-SMG

Product Information

TECHNICAL SPECS
  • Input Power: 24V DC, 250mA max.
  • Output Power: 3.2W at 4 Ohm / 1.8W at 8 Ohm.
  • Total Harmonic Distorsion: 10%.
  • PSRR: 77 dB typ @ 1kHz.
  • I2S Sample Rates: 8kHz to 96kHz.
  • Sound Pressure Range: 38-49dB.
  • Sound Masking:
    – White Noise.
    – Pink Noise.
    – Brown Noise.
  • Audio Coverage Area: Up to 80 sq. ft. (standard 8’ ceiling).
  • Dimensions: 3.54” x 1.7” x 1.36” (90 x 43.2 x 34.5 mm).
  • Max Bluetooth Range: 200ft (60m) line of sight.

    Range is highly dependent on the integration of fixtures, environment, and conditions. It is recommended to conduct testing for range accuracy.

  • Adjustable Volume.
  • Integration with Microphone and Motion Sensor.
  • Programmable settings can be set through the UltraLink+ mobile app.
  • Advanced functionality available with the optional UltraLink+ Dashboard.
  • Suitable for Indoor use.
  • Mobile app available for iOS and Android devices.
  • Open-Plan Office.
  • Education.
  • Hospitality.
  • Healthcare.
  • Government.
  • FCC
  • RoHS
