The ULPLUS-SC is a Bluetooth NLC Wireless Shade Controller for drapes and blinds.
Powered directly by the motor, no external supply is required. Drapes and blinds can be controlled with a smartphone or tablet, compatible keypads and touchscreens, occupancy sensors, and schedulers for flexible shade control and scene integration with or without lighting.
It connects via Bluetooth and can be accessed with the UltraLink+ web portal or mobile app for setup and configuration.
Product Information
TECHNICAL SPECS
FEATURES
LISTINGS
TECHNICAL SPECS
- Input Power: 5V DC to 30 V DC.
- Connector: RJ45 Female (Cat 6).
- Compatible Protocols: RS485/RS232.
- Operating Temperature: -50°F to 104°F (10° to 40°C).
- Dimensions: 3.5” x 1.7” x 1.36” (90 x 43.2 x 34.5mm).
- Max Bluetooth Range: 200ft (60m) line of sight.
Range is highly dependent on the integration of fixtures, environment, and conditions. It is recommended to conduct testing for range accuracy.
FEATURES
- Easy Installation, Plug & Play.
- No External Power Supply Needed.
- Programmable settings can be set through the UltraLink+ mobile app.
- Advanced functionality available with the optional UltraLink+ Dashboard.
- Suitable for Indoor use.
- Mobile app available for iOS and Android devices.
LISTINGS
- FCC
- RoHS
